New
- Selectable Continuous Fan Speed
- System Diagnostics LED with Fault Recall
- Twin
- Third Fan Speed
- Two-Stage Cooling Y2 Input
- 120 VAC Ignitor Output
- 120 VAC Humidifier Output
- 120 VAC Electronic Air Cleaner Output
- 120 VAC 2-Speed PSC Circulator Output
- Fuse Protection - 5 Amp
- Heat Fan OFF Delay (Dipswitch Selectable)
- Y, Y2, W, R, G, C, TWIN Terminals
Features
- Combination Gas Valve
- Single Stage
- Fast Opening
- Inlet / Outlet pressure taps
- Plastic hose barb (for connection to 1/4"hose/flexible tubing)
- LP gas conversion kit
- Inlet/Outlet reducer bushings (1/2 NPT x 3/8 NPT)
- Regulator calibrated to 3.5 ± 0.3"
- This valve is a replacement for 36G22-502
Specifications:
- Type: Single Stage
- Opening Characteristics (standard, step): Standard
- Capacity @ 1 in. p.d.: 130,000 BTU/hr; 20,000 BTU/hr minimum
- Pressure Ratings: 1/2 psi, or 3.5 kPa
- Pressure Regulator Setting: 3.5 in. wc (psi), or 0.87 kPa
- Pilot Gas Outlet: Compression fitting for 1/4 in. OD tubing
- Pressure Tapping: 1/8 in. NPT with plug
- Electrical Connections: Combination screw and 1/4 in. male quick connects
- Electrical Ratings: 24 Vac
- Frequency: 60 Hz
- Anticipator Setting: 0.5 A
- Temperature Range: 0° to 175°F, or -18° to +79°C
- Mounting: 0 to 90 degrees in any direction from the upright position of the gas control knob, including vertically
- Dimensions (in.): 5 3/16 in high x 4 1/8 in. wide x 3 1/4 in. deep
Â
Performance Specs & Compatibility
- Ports: 4-port manifold (high, low, vacuum, charge)
- Use: Charging, recovery, evacuation with micron verification
- Refrigerant library and temp inputs per Fieldpiece specifications
Why SM482V Stands Out
- Full-featured SMAN platform with 4-port flexibility plus onboard micron measurement.
Certifications & Compliance:
- Meets ARI 780/790 Standard
User Reviews & Q&A Summary:
- Common theme is "correct part" for the intended replacement, with users reporting it worked as expected after installation
- Review feedback frequently mentions straightforward installation for a direct replacement
- Value and fulfillment are recurring positives (good deal/price and fast shipping)
Product Highlights
208/240V
Specs
| OEM: | York |
|---|
Reviews
Clear filtersThere are no reviews yet.
